GAF Series
Product Type: Suction Shoe Technology
GAF Series combines our patented suction shoe gear pump with our exclusive EagleDrive technology. The result, a compact pumping package that easily integrates into your system design to support differential pressures up to 17 bar (250 psi).
0.092 ml/rev (T23)
500-5500 RPM
46 mL/min | 0.73 US gal/hr
506 mL/min | 0.134 US gpm
17.2 bar | 250 psi
21 bar | 300 psi
-46 to 149 °C | -50 to 300 °F
0.5 to 1500 cP
0.34 kg | 0.75 lbs
1/8"-27 NPT(F)
- Extended Differential Pressure (up to 250 psi)
- Small Size
- Smooth, Pulseless Delivery
- Chemically Resistant
- Easy to Service
- Proven Reliability
- Advanced Pump Technology
- OEM Configurations
- Enhanced Efficiency
- Gear Set T23: 0.092 ml/rev (0.02 US gal/1000 rev)
- Magnetic Drive Gear Pump
- Suction Shoe Style
- Spur Gears
- Stationary Shafts
- O-ring Seal
- Base Materials
- 316 Stainless Steel
- Gears
- PEEK
- Static Seals
- EPDM
- Driven
- Rare Earth
- Driving
- Electromagnetic
- Details
- Features
- Applications
- Documents
Displacement
0.092 ml/rev (T23)
Recommended Speed Range
500-5500 RPM
Flow Rate (min)
46 mL/min | 0.73 US gal/hr
Flow Rate (max)
506 mL/min | 0.134 US gpm
Differential Pressure (max)
17.2 bar | 250 psi
System Pressure (max)
21 bar | 300 psi
Temperature Range
-46 to 149 °C | -50 to 300 °F
Viscosity Range
0.5 to 1500 cP
Weight
0.34 kg | 0.75 lbs
Standard Ports
1/8"-27 NPT(F)
- Extended Differential Pressure (up to 250 psi)
- Small Size
- Smooth, Pulseless Delivery
- Chemically Resistant
- Easy to Service
- Proven Reliability
- Advanced Pump Technology
- OEM Configurations
- Enhanced Efficiency
- Gear Set T23: 0.092 ml/rev (0.02 US gal/1000 rev)
- Magnetic Drive Gear Pump
- Suction Shoe Style
- Spur Gears
- Stationary Shafts
- O-ring Seal
- Base Materials
- 316 Stainless Steel
- Gears
- PEEK
- Static Seals
- EPDM
- Driven
- Rare Earth
- Driving
- Electromagnetic
